Replaceable Parts (DSA/DPO70000B Series)
Table 5-8: Replaceable parts – External 2 (DSA/DPO70000B Series)
Fig. & Tektronix
index part
number number
5-9
-1 174-5226-00
-2 211-1050-00
-3 200-4936-00
200-5007-00
200-5007-00
-4 200-5067-00
-5 212-0232-00
-6 367-0528-00
407-4887-00
-7 348-1515-00
-8 211-1224-00
-9 348-1817-00
5–18
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
EXTERNAL PARTS
1 CABLE ASSY; LINE FILTER
16 SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
1 COVER; EMI BOTTOM, DPO/DSA70804/70604/70404
1 COVER; EMI BOTTOM, DPO/DSA720004/71604/71254
1 COVER; EMI BOTTOM, DPO/DSA7
1 COVER, BOTTOM; COSMETIC; W/FEET
2 SCREW,MACHINE; 8-32 X 1.125L, PNH, STL, BLACK ZINC SPEC
#ASTM B633 TYPE II, T-20
1 HANDLE, CARRYING; DUAL DUROMETER MOLDED,
POLYPROPYLENE, VINYL GRIP SECTION
1
BRACKET; HANDLE BASE, PC/ABS ALLOY, BAYER BAYBLEND FR-110,
TEK BLUE
1 FEET, CABINET; BLACK, GLASS-FIBRE REINFORCED PLASTIC, SET
OF 4 FEET, 4 RUBBER INSERTS
4 SCREW, MACHINE, BLACK
2 FOOT, SKID
