Tektronix MSO70000 Series Service Manual page 164

Replaceable Parts (MSO/DPO5000 Series)
Table 5-29: Replaceable parts – External parts (MSO/DPO5000 Series)
Figure
and Serial
index Tektronix no.
no. part no. effective
5-31-
-1 200-5130-00
-2 065-0858-00
-3 355-0298-00
-4 211-1272-00
-5 200-5155-00
-6 016-2029-00
5–60
Serial
no.
discont'd Qty.
1
1
2
6
1
1
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Name and description
EXTERNAL PARTS
FRONT PROTECTIVE COVER
REAR CASE
STUD, SNAP: 0.570 DIAMETER, 0.165 THICK, STAINLESS STEEL
SCREW, MACHINE: 6–32 x 0.250, PNH, STL, ZNPL, T-15 TORX DRIVE
- - - - - - DISTRIBUTION OF THE 211-1272-00 SCREWS - - - - - - -
2 screws attach the snaps to the top of the rear case
4 screws attach the rear case to the rear chassis.
COVER, DOOR, HARD DRIVE
POUCH, ACCESSORY, BLACK, SNAP ON
