Rational iCombi Pro Original Installation Instructions page 30

5 | Setup
Gas devices
Install the gas device with a minimum distance between the flue gas pipes of
the device and the grease filters of the extractor hood/ventilation ceiling.
x [mm]
x [inch]
Condensation breaker
If the steam from the ventilation pipe cannot be fed directly into an extractor
hood or ventilation ceiling, there must be a minimum distance between the
device and the ceiling.
This space is needed to install a condensation breaker that can be used to di-
rect the exhaust air into uncritical areas.
30 / 96
Minimum distance from ceiling
400
16
80.06.083_iCombiPro-iCombiClassic_IM_en-US
