Accessories

A detailed overview with part numbers can be found in the accessories catalog.
Accessories
Stands UG I – XS
Left and right heat shield
Leveling frame for tabletop de-
vices
Device extension for tabletop
devices
Device extension for floor de-
vices
Transport trolley for mobile
oven racks (standard or Combi-
Duo)
Mobile oven rack extension
Entry ramp for floor devices
Condensation breaker
80.06.083_iCombiPro-iCombiClassic_IM_en-US
Description
Different stands, with or without support rails for
storage of accessories and partially closed. The
stands can be extended with swivel castors or fixed
feet for varying installation variants.
If a sufficient distance to the heat source on the left
cannot be maintained, an additional heat shield is
available to reduce the thermal load.
For the device sizes 6 half size GN and 10 half size
GN, an additional heat shield is available for the right
side.
If the installation surface is not horizontal, this can be
compensated by a leveling frame. The adjustment
range is +/- 20 mm [3/4 inch].
Suitable for device sizes 6 half size GN and 10 half
size GN with a depth of at least 700 mm [27.6 inch].
If the distance to the work surface is insufficient, the
unit can be raised by 150 mm [5.91 inch].
If the floor distance is too small for floor devices, the
distance can be increased by extending the device
feet by 70 mm [2.76 inch].
Recommended for use with mobile oven racks. Two
variants for tabletop devices (standard) or Combi-
Duo with different docking systems. Requires the re-
spective correct feed track. The standard transport
trolley is also available with height adjustment to
compensate for height differences during installa-
tion.
If the feet of floor devices with a foot extension are
raised, a mobile oven rack extension (70 mm [2.76
inch]) must be fitted to compensate for the mobile
oven rack.
If the installation surface in the entry area of the mo-
bile oven rack is not horizontal for floor devices, this
can be compensated for by means of an entry ramp.
The adjustment range of the plate feet is +/- 10 mm
[0.39 inch].
Extending the ventilation pipe without a condensa-
tion breaker can cause the unit to malfunction.
Installation of the condensation breaker and the in-
cluded pipes ensures that escaping steam can be di-
