If this distance to the left side of the device is not possible, place the device so
that it can be pulled out of the location for maintenance work.
x (mm)
x (inch)
Recommended distance to the right side of the device
To open the device door at the first grid, place the device on the right with a
recommended minimum distance to the wall. The distance depends on the de-
vice size, as shown in the table below.
Unit size
z (mm)
z (inch)
80.06.083_iCombiPro-iCombiClassic_IM_en-US
Distance to the left side of the device
XS
6 half
size
214
246
8 1/2
10
500
20
6 full
10 half
size
size
316
246
12 1/2
10
10 full
20 half
size
size
316
268
12 1/2
11
5 | Setup
20 full
size
338
13
27 / 96
