FUSION SPRAYERS READDRESSING CANBUS MOTOR VALVE ID'S
This guide shows you how to readdress the
ID numbers in the CANBUS valves used on
the Fusion sprayers.
Before starting the below process ensure ALL
CANBUS valves are unplugged except the valve
you are programming.
On the spray screen press "Cal"
then press the red cog in the bottom right of the screen.
This will open a screen called "Section controls". Press and
hold the red cog in the bottom right corner and after 3
seconds a pin code screen will appear, enter 6 7 8 9 and
press the tick. Now press on "Valve Id #" and it will ask
for another pin code, enter 4 3 2 1 and press OK. This will
now open a screen called "Canbus Valves" and you will
need to press on "Arag reprogram" and enable this setting.
You can now press on "Valve Id #" and set the ID number
you want to program into the new valve. Using the tables
below enter the correct valve ID number and press the tick.
Press the X in the top right corner to return to the "Section
controls" screen. The final step is to press the "Reset Id"
button and you have now programmed the ID selected
into the new valve. All other CANBUS valves can now be
plugged back in.
38
HT-OMFUSION-A
2 Row Machines
Valve ID Number
Tier 1 Left 0
Tier 1 Right 1
Tier 2 Left 2
Tier 2 Right 3
Dump 16
Left Recapture 17
Right Recapture 18
Servo 19
3 Row Machines
Valve ID Number
Tier 1 Inner Left 0
Tier 1 Inner Right 1
Tier 1 Outer Left 2
Tier 1 Outer Right 3
Tier 2 Inner Left 4
Tier 2 Inner Right 5
Tier 2 Outer Left 6
Tier 2 Outer Right 7
Dump 16
Servo 19
