Setting A Simulated Spray Speed - Croplands QUANTUM FUSION Operator's Manual

SECTION 5
SETTINGS & PROGRAMMING

Setting a Simulated Spray Speed

If turning off individual spray heads & nozzles or using
specialty nozzles for a particular application, it is
advisable to perform a stationary spray pressure test.
To do this we need to give the sprayer a "Simulated Spray
Speed" to replicate working conditions.
1. AUTO model must be selected.
2. Press CAL (Spray settings) MENU.
3. Press the SIM button.
4. Press the SIM / GPS SPEED function and select ON.
5. Press the SIM SPEED MANUAL function and set the
normal desired working speed (8 km/hr).
6. Return to the Main Spray screen.
Although stationary the Sprayer now thinks it is traveling at
8 km/hr.
In AUTO model commence spraying to perform a Spray
pressure test.
NOTE: When a stationary test has been
completed the SIM Speed function must be
turned OFF.
1. Press CAL (Spray Settings) MENU.
2. Press SIM. Press SIM / GPS SPEED function and select
OFF.
