General

General

Symbols Used

The following symbols are used in this document:
i
Measure

Warnings

Disconnect the power supply before touching the sensor surface.
> Risk of injury, static discharge
Connect the power supply and the display/output device according to the safety regulations for
electrical equipment.
> Risk of injury, damage to or destruction of the sensor and/or the controller
Avoid shocks and impacts to the sensor and the controller.
> Damage to or destruction of the sensor and/or the controller
The supply voltage must not exceed the specified limits.
> Damage to or destruction of the sensor and/or the controller
Protect the sensor cable against damage.
> Destruction of the sensor, failure of the measurement system.
capaNCDT 6220/6222/6230
Indicates a hazardous situation which, if not avoided, may result in minor or
moderate injury.
Indicates a situation that may result in property damage if not avoided.
Indicates a user action.
Indicates a tip for users.
Indicates hardware or a software button/menu.
Sensor measurement direction
Page 3
