Figure 1.2. Exploded View Enclosure Type A.
1
2
3
4
5
6
7
8
9
4
1
18
17
16
15
Local control panel (LCP)
RS-485 serial bus connector (+68, -69)
Analog I/O connector
LCP input plug
Analog switches (A53), (A54)
Cable shield connector
Decoupling plate
Grounding clamp (PE)
Shielded cable grounding clamp and
strain relief
2
3
8
14
13
10
11
12
13
14
15
16
17
18
4
5
6
7
8
9
10
11
12
Motor output terminals 96 (U), 97 (V), 98
(W)
Relay 2 (01, 02, 03)
Relay 1 (04, 05, 06)
Brake (-81, +82) and load sharing (-88,
+89) terminals
Line power input terminals 91 (L1), 92
(L2), 93 (L3)
USB connector
Serial bus terminal switch
Digital I/O and 24 V power supply
Cover
