Table 6.6. Pulse Start/Stop.
Figure 6.3. Latched Start/Stop Inverse.
Speed
31-00559-01
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
Latched Start (18)
Stop Inverse (27)
Parameters
Function Setting
5-10 Terminal [9] Latched
18 Digital Input Start
5-12 Terminal [6] Stop
27 Digital Input Inverse
* = Default Value
Notes/comments:
53
