8.8.2 UL Compliance
Table 8.30. 3x200–240 V, Enclosure Types A, B and C.
Recommended Max. Fuse
Power
(hp [kW])
1.5 [1.1]
2 [1.5]
3 [2.2]
5 [3.7]
7.5–10
[5.5–7.5]
15 [11]
20 [15]
25–30
[18.5–22]
40 [30]
50 [37]
60 [45]
Table 8.31. 3x200–240 V, Enclosure Types A, B and C.
Recommended Max. Fuse
1.5 [1.1]
2 [1.5]
3 [2.2]
5 [3.7]
7.5–10
[5.5–7.5]
15 [11]
20 [15]
25–30
[18.5–22]
40 [30]
50 [37]
60 [45]
1) KTS fuses from Bussmann may substitute KTN for 240 V adjustable frequency drives.
2) FWH fuses from Bussmann may substitute FWX for 240 V adjustable frequency drives.
3) A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V adjustable frequency drives.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V adjustable frequency drives.
99
Bussmann
Bussmann
1
Type J
Type RK1
KTN-R-10 JKS-10
KTN-R-15 JKS-15
KTN-R-20 JKS-20
KTN-R-30 JKS-30
KTN-R-50 JKS-50
KTN-R-60 JKS-60
KTN-R-80 JKS-80
KTN-R-125 JKS-125
KTN-R-150 JKS-150
KTN-R-200 JKS-200
KTN-R-250 JKS-250
5017906-010 KLN-R-10
5017906-016 KLN-R-15
5017906-020 KLN-R-20
5012406-032 KLN-R-30
5014006-050 KLN-R-50
5014006-063 KLN-R-60
5014006-080 KLN-R-80
2028220-125 KLN-R-125
2028220-150 KLN-R-150
2028220-200 KLN-R-200
2028220-250 KLN-R-250
Bussmann Bussmann
Type T Type CC
JJN-10 FNQ-R-10
JJN-15 FNQ-R-15
JJN-20 FNQ-R-20
JJN-30 FNQ-R-30
JJN-50 —
JJN-60 —
JJN-80 —
JJN-125 —
JJN-150 —
JJN-200 —
JJN-250 —
ATM-R-10 A2K-10-R FWX-10
ATM-R-15 A2K-15-R FWX-15
ATM-R-20 A2K-20-R FWX-20
ATM-R-30 A2K-30-R FWX-30
— A2K-50-R FWX-50
— A2K-60-R FWX-60
— A2K-80-R FWX-80
— A2K-125-R FWX-125
— A2K-150-R FWX-150
— A2K-200-R FWX-200
— A2K-250-R FWX-250
Bussmann Bussmann
Type CC Type CC
KTK-R-10 LP-CC-10
KTK-R-15 LP-CC-15
KTK-R-20 LP-CC-20
KTK-R-30 LP-CC-30
— —
— —
— —
— —
— —
— —
— —
— — HSJ-10
— — HSJ-15
— — HSJ-20
— — HSJ-30
— — HSJ-50
— — HSJ-60
— — HSJ-80
— — HSJ-125
L25S-150 A25X-150 HSJ-150
L25S-200 A25X-200 HSJ-200
L25S-250 A25X-250 HSJ-250
