Table 8.3. Line Power Supply 3x200–240 V AC - Normal overload 110% for 1 minute,
25 to 60 HP.
Type Designation, HVFD3D...
Typical Shaft Output [HP] at 208 V
Typical Shaft Output [kW]
Enclosure Size
IP21/NEMA 1
IP55/NEMA 12
Output Current
Continuous (3x200–240 V) [A]
Intermittent (3x200–240 V) [A]
Continuous kVA (208 V AC) [kVA]
Max. Input Current
Continuous (3x200–240 V) [A]
Intermittent (3x200–240 V) [A]
Additional Specifications
Estimated power loss at rated max. load [W]
IP21, IP55 max. cable cross-section (line
power, motor) [AWG/(mm
IP21, IP55 max. cable cross-section (brake,
load sharing) [AWG/(mm
Efficiency
1) Efficiency measured at nominal current. For energy efficiency class see Chapter 8.4 Ambient
Conditions.
2) Applies for dimensioning of frequency converter cooling. If the switching frequency is higher than the
default setting, the power losses may increase. LCP and typical control card power consumptions are in-
cluded.
31-00559-01
2
)]
2
)]
1
3A0250 3A0300
25 30
18.5 22
C1 C1
C1 C1
74.8 88.0
82.3 96.8
26.9 31.7
68.0 80.0
74.8 88.0
2 737 845
1/0 (50)
1/0 (50)
0.96 0.97
3A0400 3A0500 3A0600
40 50 60
30 37 45
C1 C2 C2
C1 C2 C2
115 143 170
127 157 187
41.4 51.5 61.2
104.0 130.0 154.0
114.0 143.0 169.0
1140 1353 1636
4/0 (95)
4/0 (95)
0.97 0.97 0.97
