Table 5.4. Legend to Figure 5.1, Indicator Lights (LEDs).
Callout
15
16
17
D. Operation Keys and Reset
Operation keys are located at the bottom of the LCP.
Table 5.5. Legend to Figure 5.1, Operation Keys and Reset.
Callout
18
19
20
21
Note: The display contrast can be adjusted by pressing [Status] and []/[] keys.
5.3.3 Parameter Settings
Establishing the correct programming for applications often requires setting func-
tions in several related parameters.
Programming data are stored internally in the adjustable frequency drive.
•
•
•
5.3.4 Uploading/Downloading Data to/from the LCP
Step 1.
Step 2.
31-00559-01
Key Light
ON Green
WARN Yellow
ALARM Red
Key
Hand On
Off
Auto On
Reset
For backup, upload data into the LCP memory
To download data to another adjustable frequency drive, connect the LCP to that
unit and download the stored settings
Restoring factory default settings does not change data stored in the LCP
memory
Press [Off] to stop the motor before uploading or downloading data.
Go to [Main Menu] 0-50 LCP Copy and press [OK].
Function
The ON light activates when the adjustable frequency
drive receives power from AC line voltage, a DC bus
terminal, or an external 24 V supply.
When warning conditions are met, the yellow WARN
light comes on and text appears in the display area
identifying the problem.
A fault condition causes the red alarm light to flash
and an alarm text is displayed.
Function
Starts the adjustable frequency drive in local
control.
• An external stop signal by control input or
serial communication overrides the local
hand on
Stops the motor but does not remove power to
the adjustable frequency drive.
Puts the system in remote operational mode.
• Responds to an external start command by
control terminals or serial communication
Resets the adjustable frequency drive manually
after a fault has been cleared.
