4.4 Wiring Schematic

Figure 4.1. Basic Wiring Schematic.
A=Analog, D=Digital
*Do not connect cable shield.
31-00559-01
3-phase
91 (L1)
power
92 (L2)
input
93 (L3)
95
PE
DC bus
88 (-)
89 (+)
50 (+10 V OUT)
+10 V DC
S201/A53
0/-10 V DC-
53 (A IN)
+10 V DC
0/4–20 mA
S202/A54
0/-10 V DC-
54 (A IN)
+10 V DC
0/4–20 mA
55 (COM A IN)
12 (+24 V OUT)
13 (+24 V OUT)
18 (D IN)
19 (D IN)
(COM D IN)
20
(D IN/OUT)
27
(D IN/OUT)
29
32 (D IN)
33 (D IN)
Switch Mode
Power Supply
10 V DC
24 V DC
15 mA
130/200 mA
+
-
+
-
ON=0/4–20 mA
OFF=0/-10 V DC -
+10 V DC
P 5-00
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
S801
24 V
0 V
5 V
24 V (NPN)
0 V (PNP)
24 V
0 V
RS-485
Interface
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
(U) 96
(V) 97
(W) 98
(PE) 99
Brake
(R+) 82
resistor
(R-) 81
relay1
03
240 V AC, 2 A
02
400 V AC, 2A (Frame D only)
01
relay2
06
240 V AC, 2 A
05
400 V AC, 2 A
04
Analog Output
(COM A OUT) 39
0/4–20 mA
(A OUT) 42
ON=Terminated
OFF=Open
S801
0 V
(N RS-485) 69
RS-485
(P RS-485) 68
*
(COM RS-485) 61
Motor
: Chassis
: Ground
21
