Table 8.28. 380–480 V, Enclosure Types A, B and C.
Enclosure
Type
A2
A3
A5
B1
B2
C1
C2
Table 8.29. 525–600 V, Enclosure Types A, B and C.
Enclosure
Type
A3
A5
B1
B2
C1
C2
31-00559-01
Power Recommended
(hp [kW]) Fuse Size
1.5–5 gG-10 (1.5–4 [1.1–3])
[1.1–4.0] gG-16 (5 [4])
7.5–10 gG-16
[5.5–7.5]
1.5–10 gG-10 (1.5–4 [1.1–3])
[1.1–7.5] gG-16 (5–10 [4–7.5])
15–25 gG-40
[11–18.5]
30–40 gG-50 (30 [22])
[22–30] gG-63 (40 [30])
50–75 gG-80 (50 [37])
[37–55] gG-100 (60 [45])
gG-160 (75 [55])
100–125 aR-200 (100 [75])
[75–90] aR-250 (125 [90])
Power Recommended
(hp [kW]) Fuse Size
3 to 10 gG-10 (7.5 [5.5])
[5.5–7.5] gG-16 (10 [7.5])
1.5–10 gG-10 (1.5–7.5
[1.1–7.5] [1.1–5.5])
gG-16 (10 [7.5])
15–25 gG-25 (15 [11])
[11–18] gG-32 (20 [15])
gG-40 (25 [18.5])
30–40 gG-50 (30 [22])
[22–30] gG-63 (40 [30])
50–75 gG-63 (50 [37])
[37–55] gG-100 (60 [45])
aR-160 (75 [55])
100–125 aR-200 (100–125
[75–90] [75–90])
Recommended
Recommended
Circuit breaker
Max. Fuse Size
(Moeller)
gG-25 PKZM0-25
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
gG-160 NZMB2-A200
aR-250 NZMB2-A250
Recommended
Recommended
Circuit breaker
Max. Fuse Size
(Moeller)
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
gG-160 (50–60 NZMB2-A200
[37–45])
aR-250 (75 [55])
aR-250 NZMB2-A250
Max. Trip
Level [A]
25
25
25
63
100
160
250
Max. Trip
Level [A]
25
25
63
100
160
250
