Step 3.
Step 4.
Step 5.
5.3.5 Changing Parameter Settings
Parameter settings can be accessed and changed from the [Quick Menu] or from
the [Main Menu]. The [Quick Menu] only gives access to a limited number of
parameters.
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.
View changes
Quick Menu Q5 - Changes Made lists all parameters changed from default set-
tings.
•
•
•
5.3.6 Restoring Default Settings
Note: Risk of losing programming, motor data, localization, and monitoring records by
restoration of default settings. To provide a backup, upload data to the LCP before
initialization.
Restoring the default parameter settings is done by initialization of the adjustable
frequency drive. Initialization is carried out through 14-22 Operation Mode (rec-
ommended) or manually.
•
•
40
Select [1] All to LCP to upload data to LCP or select [2] All from LCP to
download data from the LCP.
Press [OK]. A progress bar shows the uploading or downloading process.
Press [Hand On] or [Auto On] to return to normal operation.
Press [Quick Menu] or [Main Menu] on the LCP.
Press []/[] to browse through the parameter groups, press [OK] to
select a parameter group.
Press []/[] to browse through the parameters, press [OK] to select a
parameter.
Press []/[] to change the value of a parameter setting.
Press []/[] to shift digit when a decimal parameter is in the editing
state.
Press [OK] to accept the change. 7. Press either [Back] twice to enter
Status, or press [Main Menu] once to enter Main Menu.
The list shows only parameters which have been changed in the current edit set-
up.
Parameters which have been reset to default values are not listed.
The message Empty indicates that no parameters have been changed.
Initialization using 14-22 Operation Mode does not reset adjustable frequency
drive settings such as operating hours, serial communication selections,
personal menu settings, fault log, alarm log, and other monitoring functions.
Manual initialization erases all motor, programming, localization, and
monitoring data and restores factory default settings.
