4.5 Access

Remove cover with a screwdriver (See Figure 4.3) or by loosening attaching screws
(See Figure 4.4).
Figure 4.3. Access to Wiring for NEMA 1 (IP21) Enclosures.
Figure 4.4. Access to Wiring for NEMA 12 (IP54/55) Enclosures.
See Table 4.1 before tightening the covers.
Table 4.1. Tightening Torques for Covers [Nm].
Enclosure
A5
B1/B2
C1/C2
No screws to tighten for A2/A3.
31-00559-01
IP55
2
2.2
2.2
23
