Table 2.1. Discharge Time.
Voltage
200–240
380–480
525–600
525–690
High voltage may be present even when the warning LED indicator lights are off.
LEAKAGE CURRENT HAZARD!
Leakage currents exceed 3.5 mA. Failure to ground the adjustable frequency
drive properly can result in death or serious injury.
•
LEAKAGE CURRENT HAZARD!
Contact with rotating shafts and electrical equipment can result in death or
serious injury.
•
•
•
UNINTENDED MOTOR ROTATION WINDMILLING!
Unintended rotation of permanent magnet motors can result in serious injury
or equipment damage.
•
INTERNAL FAILURE HAZARD!
An internal failure in the adjustable frequency drive can result in serious injury
when the adjustable frequency drive is not properly closed.
•
31-00559-01
Minimum waiting time (minutes)
4
1.5–5 hp
[1.1–3.7 kW]
1.5–10 hp
[1.1–7.5 kW]
1.5–10 hp
[1.1–7.5 kW]
Ensure correct grounding of the equipment by a certified electrical installer.
Ensure that only trained and qualified personnel perform installation, start-
up, and maintenance.
Ensure that electrical work conforms to national and local electrical codes.
Follow the procedures in this manual.
Ensure that permanent magnet motors are blocked to prevent unintended
rotation.
Before applying power, ensure all safety covers are in place and securely
fastened.
7 15
7.5–60 hp
[5.5–45 kW]
15–125 hp
[11–90 kW]
15–125 hp
[11–90 kW]
20
75-125 hp
[55-90 kW]
150-250 hp
[110-160 kW]
150-200 hp
[110-132 kW]
13
