Table 8.16. Torque Characteristics Frame D.
Starting torque (Constant torque)
Overload Torque (Constant torque)
1) Percentage relates to the nominal current of the drive.
2) Once every 10 minutes.

8.4 Ambient Conditions

Table 8.17. Environment.
Enclosure Ratings
Vibration Test
Max. relative Humidity
Aggressive environment (IEC 60068-2-43) H2S
test
Ambient temperature
Derating for high ambient temperature, see special conditions in the Design Guide
Minimum ambient temperature during full-scale
operation
Minimum ambient temperature at reduced
performance
Temperature during storage/transport
Maximum altitude above sea level without
derating
Derating for high altitude, see special conditions in the Design Guide
EMC Standards, Emission
EMC standards, Immunity

8.5 Cable Specifications

Table 8.18. Cable lengths and cross-sections for control cables.
Maximum motor cable length, shielded/armored
Maximum motor cable length, unshielded/unarmored
Maximum cross-section to motor, mains, load sharing, and brake
Maximum cross-section to control terminals, flexible/ rigid wire
without cable end sleeves
Maximum cross-section to control terminals, flexible wire with
cable end sleeves
91
maximum 150% for 60 s
maximum 150% for 60 s
NEMA1/IP21 (All Frame Sizes)
NEMA12/IP55 (Frame A, B, C)
NEMA12/IP54 (Frame D)
1.0 g
5%-93% (IEC 721-3-3; Class 3K3 (non-
condensing) during operation
class Kd
Max 122°F [50°C] (24-hour average maximum
113°F [45°C])
32°F [0°C]
14°F [-10°C]
-13°-+149/158°F [-25-+65/70°C]
3,300 ft [1000 m]
EN 61800-3
EN 61800-3
500 ft [150 m]
1,000 ft [300 m]
See Chapter 8.1 Electrical Data
16 AWG [1.5 mm
18 AWG [1 mm
1, 2
1, 2
2
]
2
]
31-00559-01
