Honeywell 3G SmartVFD HVFD3D3A0015 Installation And User Manual page 8

1.3.2 Exploded Views
Figure 1.1. Exploded View Enclosure Types B and C.
1
1
2
3
4
5
6
7
8
9
10
31-00559-01
2
Local control panel (LCP)
Cover
RS-485 serial bus connector
Digital I/O and 24 V power supply
Analog I/O connector
Cable shield connector
USB connector
Serial bus terminal switch
Analog switches (A53), (A54)
Relay 1 (01, 02, 03)
10
9
8
61 68 39 42 50
3
7
4
5
17
16
19
18
11 Relay 2 (04, 05, 06)
12 Lifting ring
13 Mounting slot
14 Grounding clamp (PE)
15 Cable shield connector
16 Brake terminal (-81, +82)
17 Load sharing terminal (DC bus) (-88,
+89)
18 Motor output terminals 96 (U), 97 (V), 98
(W)
19 Line power input terminals 91 (L1), 92
(L2), 93 (L3)
12
11
53 54
6
FAN MOUNTING
13
14
15
3
