1-5* Load-Indep. Setting
1-6* Load-Depend. Settg.
1-7* Start Adjustments
1-8* Stop Adjustments
31-00559-01
1-35 Main Reactance (Xh)
1-36 Iron Loss Resistance (Rfe)
1-37 d-axis Inductance (Ld)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-46 Position Detection Gain
1-50 Motor Magnetization at Zero
Speed
1-51 Min Speed Normal Magnetiz-
ing [RPM]
1-52 Min Speed Normal Magnetiz-
ing [Hz]
1-58 Flystart Test Pulses Current
1-59 Flystart Test Pulses Frequency
1-60 Low Speed Load Compensa-
tion
1-61 High Speed Load Compensa-
tion
1-62 Slip Compensation
1-63 Slip Compensation Time Con-
stant
1-64 Resonance Dampening
1-65 Resonance Dampening Time
Constant
1-66 Min. Current at Low Speed
1-70 PM Start Mode
1-71 Start Delay
1-72 Start Function
1-73 Flying Start
1-77 Compressor Start Max Speed
[RPM]
1-78 Compressor Start Max Speed
[Hz]
1-79 Compressor Start Max Time to
Trip
1-80 Function at Stop
1-81 Min Speed for Function at
Stop [RPM]
1-82 Min Speed for Function at
Stop [Hz]
1-86 Trip Speed Low [RPM]
1-87 Trip Speed Low [Hz]
1-9* Motor Temperature
1-90 Motor Thermal Protection
1-91 Motor External Fan
1-93 Thermistor Source
2-** Brakes
2-0* DC Brake
2-00 DC Hold/Preheat Current
2-01 DC Brake Current
2-02 DC Braking Time
2-03 DC Brake Cut-in Speed [RPM]
2-04 DC Brake Cut-in Speed [Hz]
2-06 Parking Current
2-07 Parking Time
2-1* Brake Energy Funct.
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-13 Brake Power Monitoring
2-15 Brake Check
2-16 AC Brake Max. Current
2-17 Over-voltage Control
3-** Reference / Ramps
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-13 Reference Site
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-19 Jog Speed [RPM]
3-4* Ramp 1
3-41 Ramp 1 Ramp-up Time
3-42 Ramp 1 Ramp-down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp-up Time
