3.2 TYPICAL WIRING

3 INSTALLATION
3.2TYPICAL WIRING

3.2.1 DESCRIPTION

The 745 contains numerous built-in features that allow for a broad range of applications. As such, it is not possible to
present connections for all possible schemes. The information in this section covers the important aspects of interconnec-
tions, in the general areas of instrument transformer inputs, other inputs, outputs, communications, and grounding.

3.2.2 REAR TERMINAL LAYOUT

3
Figure 3–6: REAR TERMINAL LAYOUT
