6.3 A2 METERING
a) MAIN MENU
PATH: ACTUAL VALUES
HARMONIC CONTENT
[ENTER] for more
The 745 can determine the harmonic components of every current that it measures. This allows it to calculate total har-
monic distortion (THD) as well as a harmonic derating factor that can be used to adjust phase time overcurrent protection to
account for additional internal energy dissipation that arises from the presence of harmonic currents.
b) HARMONIC SUB-COMPONENTS
PATH: ACTUAL VALUES
2nd HARMONIC
[ENTER] for more
6
The 745 is capable of measuring harmonic components up to a frequency of 21 times nominal system frequency. An actual
value is calculated for each phase of each monitored winding. The example above shows what is displayed in a typical
case for harmonic components (in this case the second harmonic). Similar displays exist for all harmonics up to the 21
The second harmonic magnitude for each phase current of Windings 1 through 3 are displayed. Values are expressed as a
percentage of magnitude of the corresponding fundamental frequency component.
