Gooxi R Series User Manual page 8

in total, and therefore it can support the maximum 512GB DDR4 RDIMM and the maximum
1,024GB LRDIMM.
以下为 G1DCN SERIES 的主要特性：
Main characteristics of G1DCN SERIES are listed as follows:
主板
处理器
芯片组
内存(系统)
PCH/SATA
LAN
系统硬盘 RAID
VGA
输入/输出接口
管理接口
Motherboard
Processor
Chipset
Memory
(system)
PCH/SATA
LAN
System hard disk
RAID
VGA
Input/output
ports
Management
interface
1.2.2 主板硬件芯片功能示意图：
Schematic diagram for functions of hardware chips on the
motherboard
深圳市国鑫恒宇科技有限公司 Shenzhen Guoxin Hengyu Technology Co., Ltd.
深圳市国鑫恒运信息安全有限公司
Intel Xeon processor E5-2600 V3/V4 series
Socket H3 (LGA2011) up to 145W CPU
Intel PCH WellsBurg C612 芯片
最大支持 512G DDR4-1600/1866/2133 ECC-RDIMM ，1024G
ECC-LRDIMM,
容量支持 8GB, 16GB, 32GB,64GB
支持10个SATA3.0 6Gb/s ports
单节点支持2*1GbE
RF/RFS/RFN机型单节点额外采用2个10Gb的SFP+网口
Intel® RSTe Support software RAID 0, 1，10,5
Aspeed AST2400 Graphics
1*VGA 端口,2*千兆以太网口,2*万兆光口，1*专用 IPMI 网口,1*主
板开关，2*USB3.0
IPMI 2.0 + KVM with dedicated LAN
Intel Xeon processor E5-2600 V3/V4 series
Socket H3 (LGA2011) up to 145W CPU
Intel PCH WellsBurg C612 chip
Support 512G DDR4-1600/1866/2133 ECC-RDIMM and 1024G
ECC-LRDIMM maximally;
Support a volume of 8GB, 16GB, 32GB or 64GB.
Support 10 SATA3.0 6Gb/s ports
The single node supports 2 1Gb Ethernet ports;
TheRF/RFS/RFN single node is designed with 2 additional 10Gb SFP+
ports.
Intel® RSTe Support software RAID 0, 1, 10,5
Aspeed AST2400 Graphics
1 VGA port, 2 1Gb Ethernet ports, 2 10Gb optical ports, 1 dedicated
IPMI port, 1 motherboard switch, 2 USB3.0 connectors
IPMI 2.0 + KVM with dedicated LAN
G1DCN SERIES
G1DCN SERIES
8
