Gooxi R Series User Manual page 17

CPU2-DIMMH2
CPU1
CPU2
USB3
GPU_PWR1
GPU_PWR2
D11
D14
D12, D13
S/N of Connector
VGA
SW1
J13
IPMI LAN
J15, J16
SFP1
D12
SFP2
D13
CPU1 Slot2
PCIEX8
CPU1 Slot1
PCIEX16
SATA0
SATA1
SATA2
SATA3
SYS_FAN1
SYS_FAN2
J20
J21
SATA_PWR1
JTPM1
DOM_PWR1
J9
深圳市国鑫恒宇科技有限公司 Shenzhen Guoxin Hengyu Technology Co., Ltd.
深圳市国鑫恒运信息安全有限公司
CPU2 内存通道 H，第 2 个 DIMM SLOT
CPU1 Socket
CPU2 Socket
USB3.0 Type Connector
8Pin GPU 显卡 1 电源连接器
6Pin GPU 显卡 2 电源连接器
Node ID LED 用来定位节点指示灯
系统状态指示灯，反映系统状态
2 个 SFP+光口指示灯
G1DCN SERIES Single-plate Connector
Description
The 15PIN VGA Connector is used to access
the VGA display.
LED-POWER Button (switch button with
bi-color indicators)
Dual-port USB3.0 Connector
1Gbps port (dedicated for IPMI)
Dual-port 1Gbps port (business port)
SFP+ 10Gbps port
SFP+ optical port indicator
SFP+ 10Gbps optical port
SFP+ optical port indicator
PCIE X8SLOT, standard signal link
PCIE X16SLOT, standard signal link
7PinSATA3.0 Connector
7PinSATA 3.0 Connector
7PinSATA 3.0 Connector
7PinSATA 3.0 Connector
4Pin temperature-controlled fan
Wafer-3PIN Connector
Wafer-3PIN Connector
HDD POWER
TPM /80Port Connector
SATA DOM Power Connector-3PIN
2Pin jumper cap is used to keep ME Firmware
under Recovery mode. Access to partial
functions of ME is limited.
Remarks
Green and yellow
Adaptive to 1000M,
100M, 10M
Adaptive to 1000M,
100M, 10M
From CPU1
From CPU1
BMC
UARTConnector
SYS UART
Connector
17
