The System is equipped with the 1600W1+1 redundant power unit (Platinum


Efficiency) and supports hot swapping.
系统采用 4 个非热插拨 8038 风扇。


The System is equipped with 4 non-hot-swappable 8038 fans.


Chipset 采用 Intel PCH C612 芯片。


Intel PCH C612 chips consist of the chipset.


单节点支持 16 根 1600/1866/2133 ECC RDIMM/LRDIMM,最大支持 1024GB


LRDIMM。
The single node supports 16 1600/1866/2133 ECC RDIMM/LRDIMMs and


supports the maximum 1,024GB LRDIMM.
单节点采用 2 个 Intel i350 的 RJ45 千兆网口。


The single node is equipped with 2 Intel i350 RJ45 1,000mbps ports.


RF/RFS/RFN 机型单节点额外采用 2 个 10Gb 的 SFP+网口。


The single node of RF/RFS/RFN type is equipped with 2 10Gb SFP+ ports.


系 统 有 独 立 的 IPMI 管 理 网 口 , 可 实 现 远 程 管 理 ， BMC 芯 片 使 用 Aspeed


AST2400。
The System is provided with standalone the IPMI port which can be used to


implement remote management. The Aspeed AST2400 chip is used as the BMC
chip.
系统有一个从 BMC 引出的 VGA 接口。


The System is provided with one VGA port on the BMC chip.


系统有 2 个 USB3.0 接口供用户使用。


The System is provided with 2 USB3.0 connectors available for the user.
1.2 主板特性 Characteristics of motherboard
1.2.1 主板参数
Parameters of motherboard
SY204-D24R SERIES 配 G1DCN SERIES 单路服务器主板，是基于 Intel X86 架构设计，
采用 INTEL Grantley-EP 平台， 基于 Intel PCH C612 芯片组， 搭配 Intel 最新一代 Haswell CPU，
兼容待发布的 Broadwell CPU，该主板支持有 2 颗 E5 CPU， 每个 CPU 支持 4 个 DDR4 通
道，每个通道具有两 DIMM SLOT。 该主板总共具有 16 个 DIMM SLOT，最大支持 512GB
容量的 DDR4 RDIMM，1024GB 容量的 LRDIMM。
SY204-D24R SERIES is equipped with the G1DCN SERIES single processor server
motherboard which is based on the Intel X86 architecture design. It is provided with the INTEL
Grantley-EP platform which is based on the Intel PCH C612 chipset. It is matched with the latest
generation of Intel Haswell CPU. It is compatible with Broadwell CPU to be released. This
motherboard supports 2 E5 CPUs, and each of these CPUs supports 4 DDR4 channels. Each of
these channels is provided with two DIMM SLOTs. This motherboard contains 16 DIMM SLOTs
