Gooxi R Series User Manual page 18

Dual processors high density server barebone
Table of Contents

Advertisement

J8
JCMOS1
BMC UART
D10
D15
SYS UART
JBAT1
CPU1-DIMMA1
CPU1-DIMMA2
CPU1-DIMMB1
CPU1-DIMMB2
CPU1-DIMMC1
CPU1-DIMMC2
CPU1-DIMMD1
CPU1-DIMMD2
CPU2-DIMME1
CPU2-DIMME2
CPU2-DIMMF1
CPU2-DIMMF2
CPU2-DIMMG1
CPU2-DIMMG2
CPU2-DIMMH1
CPU2-DIMMH2
CPU1
CPU2
USB3
GPU_PWR1
GPU_PWR2
D11
D14
D12, D13
深圳市国鑫恒宇科技有限公司 Shenzhen Guoxin Hengyu Technology Co., Ltd.
深圳市国鑫恒运信息安全有限公司
ME UPDATE, 2Pin jumper cap used for
upgrading ME
2Pin jumper cap used for clearing CMOS
3Pin BMC Debug RS232 Connector
BMC Heart LED
Power status indicator
3Pin System Debug RS232 Connector
CR2032 Battery Socket
Memory channel A of CPU1, the first DIMM
SLOT
Memory channel A of CPU1, the second
DIMM SLOT
Memory channel B of CPU1, the first DIMM
SLOT
Memory channel B of CPU1, the second
DIMM SLOT
Memory channel C of CPU1, the first DIMM
SLOT
Memory channel C of CPU1, the second
DIMM SLOT
Memory channel D of CPU1, the first DIMM
SLOT
Memory channel D of CPU1, the second
DIMM SLOT
Memory channel E of CPU2, the first DIMM
SLOT
Memory channel E of CPU2, the second
DIMM SLOT
Memory channel F of CPU2, the first DIMM
SLOT
Memory channel F of CPU2, the second
DIMM SLOT
Memory channel G of CPU2, the first DIMM
SLOT
Memory channel G of CPU2, the second
DIMM SLOT
Memory channel H of CPU2, the first DIMM
SLOT
Memory channel H of CPU2, the second
DIMM SLOT
CPU1 Socket
CPU2 Socket
USB3.0 Type Connector
8Pin GPU display card 1 power connector
6Pin GPU display card 2 power connector
Node ID LED used to locate node indicator
System status indicator used to reflect system
status
2 SFP+ optical port indicators
18
