Manual restart
In automatic operation, the regulator limits the number of motor starts.
5.5

During operation

Control panel
Procedure
Step
1
2
3
84
Control panel of Elektronikon controller
When operation sign (4) is alight, starting and stopping of the motor is automatically
controlled: when the motor is stopped, it may restart automatically.
Action
Check the readings on the touchscreen (1).
When reaching the preset unloading pressure, shown on the touchscreen (1), the
compressor will start running unloaded. From now on, the electronic control module will
calculate the optimum moment to stop and restart the compressor motor automatically,
depending on the maximum permissible number of motor starts and on the air
consumption.
To unload the compressor manually, select Unload on the touchscreen.
To put the compressor back into automatic operation, select Load on the touchscreen.
