Heat exchanger
PED Category
Design code
Material
Bolts
Interval of periodic
inspection by 3rd
party (1)
Casting factor
Minimum wall
thickness after
corrosion
Medium
Volume
Design pressure
Design temperature 95 °C
(1) The maintenance instructions given in the user manual must be applied by the user.
AIF999999
ZR 160-275
CAT II
ASME BPVC Section VIII, div 1
SA-395
8.8
5 years or the frequency as given in national legislation
Intercooler
0.8
Covers : 8 mm
Shell : 10 mm
Shellside
Water, group 2
92 l
15 bar
Name
Intercooler
Aftercooler
Position of data plate
Tubeside
Air, group 2
21.4 l
4.5 bar
240 °C
Aftercooler
0.8
Covers : 8 mm
Shell : 10 mm
Shellside Tubeside
Water, group 2 Air, group 2
See intercooler 17.6 l
15 bar 13.7 bar
95°C 240 °C
