Description
Air drawn through the filter (AF) is compressed in the low-pressure compressor element (El).
On ZR compressors, the compressed air is discharged to the intercooler (Ci).
The cooled air is further compressed in the high-pressure compressor element (Eh) and
discharged through the silencer (AS) and aftercooler (Ca).
On ZR/ZT 110 up to ZR/ZT 275, a check valve (CV) is fitted downstream of the silencer.
The compressed air leaves the compressor via the air outlet (AO).
14
Name
Silencer
By-pass valve
Aftercooler
Intercooler
Oil cooler
Check valve
High-pressure compressor element
Low-pressure compressor element
Moisture trap, aftercooler
Moisture trap, intercooler
Oil filter
Oil pump
