Input/output Q
Connection ........................................................... Q,
max. connecting wire length (recommended) ....10 m
Low voltage level (output) ..............................0...2 V
High voltage level (output) ........................ 10 V...U
Output M+
Connection ....................................................... M+,
max. cable length (recommended) .....................10 m
max. load ...........................................................20 mA
Burden
current output ...............................................≤ 600 Ω
Voltage output ................................................> 2 k Ω
Tolerance with respect to final current/voltage value
.........................................................................±20 %
Connections .............................................................
terminals .......................plug-in screw-type terminals
Terminal series ... Phoenix Contact MC 1,5/ -ST-3,5 BK
Connection properties
rigid ................................................ 0.14 ...1.5 mm²
flexible, ferrule ...........................................................
without plastic sleeve ...................... 0.25...1.5 mm²
with plastic sleeve ........................... 0.25...0.5 mm²
Stripping length .................................................7 mm
Tightening torque .............................. 0.22...0.25 Nm
Conductor cross section AWG.......................... 28
EMC/Environment
EMC ..........................................................IEC 62020-1
Operating temperature ..........................-40...+70 °C
Transport .............................................. -40...+85 °C
Long-time storage .................................-40...+70 °C
Classification of climatic conditions acc. to IEC 60721
(except condensation and formation of ice)
Stationary use (IEC 60721-3-3) ..........................3K24
Transport (IEC 60721-3-2) ..................................2K11
Long-term storage (IEC 60721-3-1) ...................1K22
Classification of mechanical conditions acc. to IEC
60721
Stationary use (IEC 60721-3-3) .........................3M12
Transport (IEC 60721-3-2) .................................. 2M4
Long-term storage (IEC 60721-3-1) ................. 1M12
Other
Operating mode ........................ continuous operation
Mounting ......................................................... vertical
Degree of protection, (DIN EN 60529)
internal components .......................................... IP30
terminals .............................................................IP20
Enclosure material ................................. polycarbonate
DIN rail mounting acc. to ............................ IEC 60715
Flammability class ........................................ UL94 V-0
Weight ...................................................................64 g
S
* Factory setting
1) The requirements of the respective standards are only met
starting with a response value of 30 mA
2) EMC influences may lead to communication interruptions
at the NFC interface
8.3 Standards & certifications
The RCMS410 device has been developed in
accordance with the following standards:
DIN EN IEC 62020-1
8.4

Licences

For a list of the open-source software used see
our homepage.
8.5

EU Declaration of Conformity

Bender GmbH & Co. KG hereby declares that
16
...
the device covered by the Radio Directive com-
plies with Directive 2014/53/EU. The full text of
the EU Declaration of Conformity is available at
the following Internet address:
EU Declaration of Conformity
8.6

Ordering information

Supply voltage U
AC/DC
RCMS410_D00424_00_M_XXEN / 09.2022
LINETRAXX® SmartDetect RCMS410
S
Type
DC
24 V RCMS410-24 B84604040
Art. no.
B84604041
B84604042
