Bender LINETRAXX SmartDetect RCMS410 Manual page 39

Register Description
4020 H1, CH2
4021 H2, CH2
4022 H3, CH2
4023 H4, CH2
4024 H5, CH2
4025 H6, CH2
4026 H7, CH2
4027 H8, CH2
4028 H9, CH2
4029 H10, CH2
4030 H11, CH2
4031 H12, CH2
4032 H13, CH2
4033 H14, CH2
4034 H15, CH2
4035 H16, CH2
4036 H17, CH2
4037 H18, CH2
4038 H19, CH2
4039 H20, CH2
Prop-
Format Bytes
erty
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
LINETRAXX® SmartDetect RCMS410
Value/Unit/Comment
1st harmonic [mA]
2nd harmonic [mA]
3rd harmonic [mA]
4th harmonic [mA]
5th harmonic [mA]
6th harmonic [mA]
7th harmonic [mA]
8th harmonic [mA]
9th harmonic [mA]
10th harmonic [mA]
11th harmonic [mA]
12th harmonic [mA]
13th harmonic [mA]
14th harmonic [mA]
15th harmonic [mA]
16th harmonic [mA]
17th harmonic [mA]
18th harmonic [mA]
19th harmonic [mA]
20th harmonic [mA]
RCMS410_D00424_00_M_XXEN / 09.2022
Measuring channel 2
39
