6.6

Monitoring-functions registers

Register Description
Monitoring functions (registers 2000...2050)
2000
2001
CT status
2002
2003
Reload memory of
2014
input/output "Q"
Reload memory of
2015
output "M+"
6.7

Status-information registers

Register Description
Status information (registers 3000...3999)
3000 Test status
3001 Status of input "I"
3002 Status of input/output "Q"
3005 Status of output "Q"
3006 Status of output "M+"
Memory status enabled
3009
input/output "Q"
Memory status enabled
3010
output "M+"
Memory status disabled
3013
input/output "Q"
Memory status disabled
3014
output "M+"
Format Bytes
CT1 UINT16 2
CT2 UINT16 2
CT3 UINT16 2
CT4 UINT16 2
UINT16 2
UINT16 2
Format Bytes
UINT16 2
UINT16 2
UINT16 2
UINT16 2
UINT16 2
UINT16 2
UINT16 2
UINT16 2
UINT16 2
LINETRAXX® SmartDetect RCMS410
Prop-
Value/Unit/Comment
erty
RO
0 = OK
RO
1 = short circuit
RO
2 = interruption
RO
RO
0 = Reload memory disabled
1 = Reload memory enabled
RO
Prop-
Value/Unit/Comment
erty
0 = no active test
RO 1 = test active via T/R button
2 = test active via interface
0 = input is not operated
RO
1 = input is operated
0 = input is not operated
RO 1 = input is operated
2 = input /output "Q" is configured as output
Current output status:
RO
0 = output disabled (none of the alarm-assignment events
occurred)
1 = output enabled (at least one of the alarm-assignment events
RO
occurred)
RO
The last enabled status (1) of the output will be retained until the
next Modbus query is made
RO
RO
The last disabled status (0) of the output will be retained until the
next Modbus query is made
RO
