S 4.1
S 3.1
S 2.1
5

Operation and settings on the device

S 1.1
5.1

RCMS410 control panel (overview)

ON
A
1
AL
B
2
Ch
1
I
∆
S 4.1
6 mA - 30 A
2
S 3.1
I
C ∆
3 10 mA - 10 A
S 2.1
4
S 1.1
RCMS410
Bender
Fig. 5–6
+ -
5.2

STATUS LED

M+ Q
Multicoloured display of various operating modes.
ON
1
AL
2
Ch
1
2
S 4.2
S 3.2
S 2.2
S 1.2
n(Type A):
S 4.2
S 3.2
n(Type B):
S 2.2
T / R
D
S 1.2
RCMS410-24 control panel
A B
I
I n(Type A):
∆
6 mA - 30 A
LINETRAXX® SmartDetect RCMS410
Control panel
STATUS LED ON – operating modes
A
ALARM LEDs – AL1 (prewarning) / AL2 (main alarm)
B
LEDs – measuring-current transformer 1, 2, 3, 4
C
T/R BUTTON – Test/Reset
D
LED Operating mode
START PHASE
Device booting after start
Green
NORMAL OPERATION
Device in fault-free state
CT FAULT
Connection fault of measuring-current trans-
Yellow,
former, LED flashes in time with the LED of the
flashing
respective faulty CT.
DEVICE ERROR
Red
Restart or replacement of the device required.
Blue and
NFC ACTIVE
green,
flashing
RCMS410_D00424_00_M_XXEN / 09.2022 29
