6.15 Function and operating-characteristics registers

Register Description
Function and response behaviour parameters (32700...32720)
32700 CT1 function
32701 CT2 function
32702 CT3 function
32703 CT4 function
32704 CT1 hysteresis
32705 CT2 hysteresis
32706 CT3 hysteresis
32707 CT4 hysteresis
32708 CT1 filter setting
32709 CT2 filter setting
32710 CT3 filter setting
32711 CT4 filter setting
Fundamental-harmonic
32712
frequency
32713 Preset factor
32714 Preset offset
Automatic switching of CT1
32715
measuring range
Automatic switching of CT2
32716
measuring range
Automatic switching of CT3
32717
measuring range
Automatic switching of CT4
32718
measuring range
Prop-
Format Bytes
erty
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
LINETRAXX® SmartDetect RCMS410
Value/Unit/Comment
1 = overcurrent
2 = undercurrent
3 = window function
4 = digital input: high-active
5 = digital input: low-active
6 = none
2...40 [%], increment 1 %
1 = no filter
2 = type A
3 = type F
4 = type B
5 = type B+
6 = 50 Hz
7 = 60 Hz
8 = 150 Hz
9 = 180 Hz
10 = 500 Hz
11 = 1000 Hz
12 = 2000 Hz
13 = 5000 Hz
14 = 10000 Hz
50...1000 Hz; increment 1 Hz
1...99; increment 1
0...30000; increment 1 [mA]
0 = disabled
1 = enabled
i
When this function is enabled, the
release time t
off
1 s.
RCMS410_D00424_00_M_XXEN / 09.2022
Factory
setting
1
1
1
1
15
15
15
15
1
1
1
1
50
3
30
1
1
can increase by up to
1
1
