Function

2.2.8 Preset function

With the adjustable preset function default values of the response values can be set for all chan-
nels. For this, the currently measured value is taken into account for every channel. The response
value is calculated by multiplying the currently measured value with a preset factor and then
adding a preset offset value.
i
These settings are configured in Modbus registers 32713 and 32714.

2.2.9 Reload function

When faults occur only for a limited time but repeatedly in the monitored system while the stor-
ing of faults in the memory is disabled, the alarm outputs would switch over to the fault status si-
multaneously. The reload function permits limiting the number of these switch-overs. As soon as
the specified number is exceeded, the fault memory switches on, and a triggered alarm remains
stored. When an adjustable time period has passed between two alarms, the counter is reset
without the fault memory being switched on.
i
The settings for this are performed in Modbus registers
32418 and 32419 (input/output Q) or 32520 and 32521 (output M+).

2.2.10 NFC interface

The NFC interface can be used to transmit a previously configured device parameter setting di-
rectly to the RCMS410.
i
This function is available only via the Bender Connect App. You can find this app in the
Appstores for
14 RCMS410_D00424_00_M_XXEN / 09.2022
I = I x preset factor + preset offset
Δn Δ
iOS and Android.
In the Bender Connect app the device first needs to be made known.
Then the device-specific setting options are shown so that they can be
configured. When the data is transferred, feedback is given whether the
parameter configuration has been successful.
The NFC antenna is located at the front on the righthand side of the
RCMS410. Parameter settings can be configurd via the Bender Connect
app by holding the mobile phone to the NFC logo at the front or at the
right sidewall.
To a de-energised device, a parameter setting can be transferred via the
Bender Connect app. This setting is then activated automatically when
the device is connected to the current supply.
Parameters can be configured via the Bender Connect App also when
the device is plugged in. To this end, the NFC interface first needs to be
activated in the device via the T/R button at the front of the device or
via the Modbus interface.
