Modbus interface
Register
Description
58013
4.74
58014
4.75
58015
4.76
58016
4.77
58017
4.78
58018
4.79
58019
4.80
58020
4.81
58021
4.82
58022
4.83
58023
4.84
58024
4.85
58025
4.86
58026
6.00
58027
6.10
58028
6.31
58029
6.51
58030
7.61
58031
7.62
58032
7.63
58033
8.20
58034
8.24
58035
8.43
58036
8.44
58037
8.45
58038
8.46
58039
8.49
50
RCMS410_D00424_00_M_XXEN / 09.2022
Prop-
Format Bytes
erty
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
Value/Unit/Comment
474 = CT4 overload
475 = invalid settting of CT1: AC, DC and/or RMS
response values are too far apart
476 = invalid settting of CT2: AC, DC and/or RMS
response values are too far apart
477 = invalid settting of CT3: AC, DC and/or RMS
response values are too far apart
478 = invalid settting of CT4: AC, DC and/or RMS
response values are too far apart
479 = invalid settting of CT1: "type B+" filter combined
with a response value >300 mA
480 = invalid settting of CT2: "type B+" filter combined
with a response value >300 mA
481 = invalid settting of CT3: "type B+" filter combined
with a response value >300 mA
482 = invalid settting of CT4: "type B+" filter combined
with a response value >300 mA
483 = invalid settting of CT1: AC response value
<10 mA or >10 A with a "type B" measuring-current
transformer
484 = invalid settting of CT2: AC response value
<10 mA or >10 A with a "type B" measuring-current
transformer
485 = invalid settting of CT3: AC response value
<10 mA or >10 A with a "type B" measuring-current
transformer
486 = invalid settting of CT4: AC response value <
10 mA or > 10 A with a "type B" measuring-current
transformer
600 = internal error
610 = internal error
631 = internal error
651 = internal error
761 = internal error
762 = internal error
763 = internal error
820 = internal error
824 = T/R button defective
843 = internal error
844 = internal error
845 = internal error
846 = internal error
849 = internal error
Revers-
Device
ible
faulty
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
