6.12 Registers of input/output "Q"

Register Description
Parameters of input/output "Q" (32400)
32400 Mode
32401 Function
32402 Test
32403 Device-error alarm assignment
32404 AC CT1 alarm assignment
32405 AC CT2 alarm assignment
32406 AC CT3 alarm assignment
32407 AC CT4 alarm assignment
32408 DC CT1 alarm assignment
32409 DC CT2 alarm assignment
32410 DC CT3 alarm assignment
32411 DC CT4 alarm assignment
32412 RMS CT1 alarm assignment
32413 RMS CT2 alarm assignment
32414 RMS CT3 alarm assignment
32415 RMS CT4 alarm assignment
Connection-fault alarm assign-
32416
ment CT1...4
Alarm assignment, overloading
32417
of the measuring channels
32418 Reload cycles
32419 Reload time
44 RCMS410_D00424_00_M_XXEN / 09.2022
Prop-
Format Bytes
erty
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
UINT16 2 RW
Value/Unit/Comment
1 = output: passive
2 = output: high-active:
3 = output: low-active
4 = output: permanently high
5 = output: permanently low
6 = input: high-active
7 = input: low-active
0 = none
Operative with modes 6...7:
1 = reset
2 = test
Operative with modes 1...3:
3 = prewarning
4 = main alarm
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0...10 = number of switching cycles until the
output status is frozen
2...60 [s] = time until reload counter will be
reset
Factory
setting
3
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
6
