6.19 Measuring-current-transformer registers

Register Description
CT - parameters (33100)
Type of measuring-current
33100
transformer, CT1
Type of measuring-current
33101
transformer, CT2
Type of measuring-current
33102
transformer, CT3
Type of measuring-current
33103
transformer, CT4
33104 Number of windings, CT1
33105 Number of windings, CT2
33106 Number of windings, CT3
33107 Number of windings, CT4

6.20 Device-error-code registers

i
Register content 0 = no error
Register Description
Device error codes (58000)
Number of device
58000
errors
58001 0.10
58002 0.11
58003 0.12
58004 0.13
58005 0.57
58006 0.58
58007 3.21
58008 3.25
58009 4.70
58010 4.71
58011 4.72
58012 4.73
Format Bytes
UINT16
UINT16
UINT16
UINT16
UINT16
UINT16
UINT16
UINT16
Prop-
Format Bytes
erty
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
Prop-
Value/Unit/Comment
erty
2 RW
2 RW
1 = "type A"/ "type F"
2 = "type B"/ "type B+"
2 RW
2 RW
i
2 RW
2 RW
2 RW
2 RW
100...1000; increment 1
Value/Unit/Comment
Number of active device errors
10 = CT-connection fault, CT1
11 = CT-connection fault, CT2
12 = CT-connection fault, CT3
13 = CT-connection fault, CT4
57 = connection fault at input/output "Q"
58 = connection fault at output "M+
321 = Internal error
325 = Internal error
470 = thermal overload at measuring inputs
471 = CT1 overload
472 = CT2 overload
473 = CT3 overload
RCMS410_D00424_00_M_XXEN / 09.2022
LINETRAXX® SmartDetect RCMS410
These registers can only be used,
when the function module "external
transformer connection" is enabled. If
not, they are reserved.
When an external transformer is
used, it is imperative that a winding
number be selected.
Factory
setting
1
1
1
1
-
-
-
-
Revers- Device
ible faulty
X
X
X
X
X
X
X
X
X
X
X
X
X
