Suitable measuring-current transformers
Type B/type B+
CTBS CTUB series
CTBS25

4.5.2 Connection of CTs of other manufacturers

External transformers can only be used with the respective function module activated. The wind-
ing number of the external transformer absolutely must be entered (registers 33104...33107).
Use residual current transformers and not load-current transformers.
Response range
The maximum response range is 6 mA ... 30 A. The actual upper limit of the response range de-
pends on the number of windings of the measuring-current transformer used:
Measuring range
The upper limit of the measuring range depends on the number of windings n of the measur-
ing-current transformer used:
Measuring range upper limit
Continuous residual current
The permissible continuous residual current depends on the number of windings n of the meas-
uring-current transformer used:
permissible continuous residual current
permissible continuous secundary current
i
Compliance with the respective product standard under „8.3 Standards & certifications"
cannot be ensured if an external transormer is used and, if necessary, needs to be as-
sessed separately after consultation with the manufacturer.
Type A/type F
CTAC series
CTUB102 CTAC20
CTAC35
CTAC60
CTAC120
CTAC210
Upper limit of response range
new
Wx series
W0-S20
W1-S35
W2-S70
W3-S105
W4-S140
W5-S210
= 30 A x n/600
new
= as per tabular data
=
new
(see chapter „8.2 Tabular data")
RCMS410_D00424_00_M_XXEN / 09.2022
LINETRAXX® SmartDetect RCMS410
Type A
WR series WS series
WR70x175S WS20x30
WR115x305S WS50x80
WR150x350S WS50x80S
WR200x500S WS80x120
WR70x175SP WS80x80S
WR115x305SP WS80x120S
WR150x350SP WS80x160S
WR200x500SP
(see chapter „8.2 Tabular data")
x n
x n/600
27
