6.13 Registers of output "M+"
Register
Description
Parameters of output "M+" (32500)
32500
Mode
32501
Function
32502
Linearity
32503
Scaling
32504
Test
32505
Device-error alarm assignment
32506
AC CT1 alarm assignment
32507
AC CT2 alarm assignment
32508
AC CT3 alarm assignment
32509
AC CT4 alarm assignment
32510
DC CT1 alarm assignment
32511
DC CT2 alarm assignment
32512
DC CT3 alarm assignment
32513
DC CT4 alarm assignment
32514
RMS CT1 alarm assignment
32515
RMS CT2 alarm assignment
32516
RMS CT3 alarm assignment
32517
RMS CT4 alarm assignment
Prop-
Format
Bytes
erty
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
UINT16
2
RW
LINETRAXX® SmartDetect RCMS410
Value/Unit/Comment
1 = output: passive
2 = output: high-active
3 = output: low-active
4 = output: permanently high
5 = output: permanently low
6 = output: 0...20 mA
7 = output: 4...20 mA
8 = output: 0...10 V
9 = output: 2...10 V
0 = none
Operative with modes 1...3:
1 = prewarning
2 = main alarm
Operative with modes 6...9:
3 = channel 1 (RMS)
4 = channel 2 (RMS)
5 = channel 3 (RMS)
6 = channel 4 (RMS)
Operative with functions 3...6:
1= linear with respect to maximum scale value
(see register 32503)
2= linear with respect to 100 % of I
Operative only with linearity 1:
0...65000 [mA], increment 1 mA, maximum
scale value
i
Note: This value can be set to max. 5 x
I
!
Δn RMS
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
0 = disabled
1 = enabled
RCMS410_D00424_00_M_XXEN / 09.2022
Factory
setting
3
2
2
Δn RMS
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
45
