Alarm/measuring-value registers

Register Description
Measured values (registers 999...1999)
999 Number of active messages
1000
1004
1008
1012
1016
1020
Max. residual-cur-
1024 rent measured
value
1028
1032
1036
1040
1044
1048
1050
1052
1054
1056
1058
Current value of
residual current
1060
1062
1064
1066
1068
1070
Format Bytes Property Value/Unit/Comment
UINT16
AC CH1 UINT8
AC CH2 UINT8
AC CH3 UINT8
AC CH4 UINT8
DC CH1 UINT8
DC CH2 UINT8
DC CH3 UINT8
DC CH4 UINT8
RMS CH1 UINT8
RMS CH2 UINT8
RMS CH3 UINT8
RMS CH4 UINT8
AC CH1 Float
AC CH2 Float
AC CH3 Float
AC CH4 Float
DC CH1 Float
DC CH2 Float
DC CH3 Float
DC CH4 Float
RMS CH1 Float
RMS CH2 Float
RMS CH3 Float
RMS CH4 Float
0...n = number of active messages (device error, alarms,
connection faults, ...)
2 RO
n is the number of messages that could also be attributed to an
output (e. g. relay)
Measured-value block: In each case the max. measured value
8 RO
incl. corresponding alarm and measuring-range states since the
8 RO
last Modbus query is output.
8 RO
Size of the measured-value block: 4 x UINT8 = 8
8 RO
8 RO Content of the measured-value block:
• Adr. Offset 0 (e. g.. 1000): measured value, part 1 [Float32_t]
8 RO
• Adr. Offset 1 (e.g. 1001): measured value, part 2 [Float32_t]
8 RO
• Adr. Offset 2 (e. g. 1002): alarm status:
8 RO
0: no alarm
8 RO
1: prewarning
2: main alarm
8 RO
• Adr. Offset 3 (z.B. 1003): measuring range:
8 RO
0: "="
1: "<"
8 RO
2: ">"
4 RO
4 RO
4 RO
4 RO
4 RO
4 RO
Currently measured value
4 RO
4 RO
4 RO
4 RO
4 RO
4 RO
