Modbus interface
6.8

Harmonic-analysis registers

Registers (4000...4500) are only available with the optional function module "harmonic analysis".
Otherwise these registers are reserved.
Register
Description
Harmonic analysis, individual values H1...20 (registers 4000...4079)
4000
H1, CH1
4001
H2, CH1
4002
H3, CH1
4003
H4, CH1
4004
H5, CH1
4005
H6, CH1
4006
H7, CH1
4007
H8, CH1
4008
H9, CH1
4009
H10, CH1
4010
H11, CH1
4011
H12, CH1
4012
H13, CH1
4013
H14, CH1
4014
H15, CH1
4015
H16, CH1
4016
H17, CH1
4017
H18, CH1
4018
H19, CH1
4019
H20, CH1
38
RCMS410_D00424_00_M_XXEN / 09.2022
Prop-
Format
Bytes
erty
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
UINT16
2
RO
Value/Unit/Comment
1st harmonic [mA]
2nd harmonic [mA]
3rd harmonic [mA]
4th harmonic [mA]
5th harmonic [mA]
6th harmonic [mA]
7th harmonic [mA]
8th harmonic [mA]
9th harmonic [mA]
10th harmonic [mA]
11th harmonic [mA]
12th harmonic [mA]
13th harmonic [mA]
14th harmonic [mA]
15th harmonic [mA]
16th harmonic [mA]
17th harmonic [mA]
18th harmonic [mA]
19th harmonic [mA]
20th harmonic [mA]
Measuring channel 1
