Modbus interface
6.9

THD, RMS registers, H1...400

Register Description
Harmonic analysis H1...400 (registers 4080...4500)
4080 THD CH1
4081 THD validity CH1
4082 THD CH2
4083 THD validity CH2
4084 THD CH3
4085 THD validity CH3
4086 THD CH4
4087 THD validity CH4
4088...
4094
Request calculation of full
4096
range
Status of full-range
4097
calculation
4098 H1...50
4148 H51...100
4198 H101...150
4248 H151...200
4298 H201...250
4348 H251...300
4398 H301...350
4448 H351...400
4498 THD full range
4499 Validity of full-range THD
42 RCMS410_D00424_00_M_XXEN / 09.2022
Prop-
Format Bytes
erty
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
UINT16 2 RO
Reserved
UINT16 2 RW
UINT16 2 RO
UINT16 100 RO
UINT16 100 RO
UINT16 100 RO
UINT16 100 RO
UINT16 100 RO
UINT16 100 RO
UINT16 100 RO
UINT16 100 RO
UINT16 2 RO
UINT16 2 RO
Value/Unit/Comment
Total of all harmonics (incl. fundamental harmonic) divided by
fundamental harmonic; value range: 0...10000 [%]
Validity of THD value; 0: =, 2: >
Total of all harmonics (incl. fundamental harmonic) divided by
fundamental harmonic; value range: 0...10000 [%]
Validity of THD value; 0: =, 2: >
Total of all harmonics (incl. fundamental harmonic) divided by
fundamental harmonic; value range: 0...10000 [%]
Validity of the THD value; 0: =, 2: >
Total of all harmonics (incl. fundamental harmonic) divided by
fundamental harmonic; value range: 0...10000 [%]
Validity of THD value; 0: =, 2: >
1 = measuring channel 1
2 = measuring channel 2
3 = measuring channel 3
4 = measuring channel 4
0 = calculation ongoing or no calculation requested
1 = calculation completed
1st - 50th harmonic [mA] of the selected measuring channel
51st - 100th harmonic [mA] of the selected measuring channel
101st - 150th harmonic [mA] of the selected measuring channel
151st - 200th harmonic [mA] of the selected measuring channel
201st - 250th harmonic [mA] of the selected measuring channel
251st - 300th harmonic [mA] of the selected measuring channel
301st - 350th harmonic [mA] of the selected measuring channel
351st - 400th harmonic [mA] of the selected measuring channel
Total of all harmonics (incl. fundamental harmonic) divided by
fundamental harmonic; value range: 0...10000 [%]
Validity of THD value; 0: =, 2: >
