Expansion Interface II

The expansion interface II allows an Analog Devices EZ-Extender or a
custom-design daughter board to be tested across various hardware plat-
forms that have the same expansion interface.
The expansion interface II implemented on the ADSP-BF518F EZ-Board
consists of four connectors, three of which are 0.1 in. shrouded headers
( ), and the last of which is a Samtec QMS series header (
P2—4
nectors contain a majority of the ADSP-BF518F processor signals. For
pinout information, go to
page B-1. The mechanical dimensions of the expansion connectors can be
obtained by contacting
For more information about daughter boards, visit the Analog Devices
Web site at:
http://www.analog.com/processors/blackfin/evaluationDevelop-
ment/crosscore/
Limits to current and interface speed must be taken into consideration
when using the expansion interface II. Current for the expansion
interface II is sourced from the EZ-Board; therefore, the current should be
limited to 1A for 5V and 500 mA for the 3.3V planes. If more current is
required, then a separate power connector and a regulator must be
designed on a daughter card. Additional circuitry can add extra loading to
signals, decreasing their maximum effective speed.
Analog Devices does not support and is not responsible for the
effects of additional circuitry.
