Programmable Flags - Analog Devices EZ-Board ADSP-BF518F Manual

is configurable over the 2-wire interface (TWI) signals. Refer to the
power-on-self test (POST) example in the ADSP-BF518F installation
directory of VisualDSP++ for information on how to set up the TWI
interface.
The core voltage and clock rate can be set on the fly by the processor. The
input clock is 25 MHz. A 32.768 kHz crystal supplies the real-time clock
(RTC) inputs of the processor. The default boot mode for the processor is
external parallel flash boot. See
page 2-8 for information on how to change the default boot mode.

Programmable Flags

The processor has 40 general-purpose input/output (GPIO) signals spread
across three ports (
depend on the ADSP-BF518F processor setup. The following tables show
how the programmable flag pins are used on the EZ-Board.
• programmable flag pins –
PF
• programmable flag pins –
PG
• programmable flag pins –
PH
Table 2-1. PF Port Programmable Flag Connections
Processor Pin Other Processor Function
PF0 ETxD2/PPID0/SPI1_SSEL2/TA
CLK6
PF1 ERxD2/PPID1/PWM_AH/TACLK7
PF2 ETxD3/PPID2/PWM_AL
PF3 ERxD3/PPID3/PWM_BH/TACLK0
ADSP-BF518F EZ-Board Evaluation System Manual
ADSP-BF518F EZ-Board Hardware Reference
"Boot Mode Select Switch (SW1)" on
, , and ). The pins are multi-functional and
PF PG PH
Table 2-1
Table 2-2
Table 2-3
EZ-Board Function
Default:
Land grid array, expansion interface II
Default:
Land grid array, expansion interface II
Default:
Land grid array, expansion interface II
Default:
Land grid array, expansion interface II
ETXD2
ERXD2
ETXD3
ERXD3
2-3
