The ADSP-BF518F EZ-Board board is designed to run outside your per-
sonal computer as a stand-alone unit. You do not have to open your
computer case.
The EZ-Board evaluation system contains ESD (electrostatic discharge) sensi-
tive devices. Electrostatic charges readily accumulate on the human body and
equipment and can discharge without detection. Permanent damage may
occur on devices subjected to high-energy discharges. Proper ESD precautions
are recommended to avoid performance degradation or loss of functionality.
Store unused EZ-Board in the protective shipping package.
When removing the EZ-Board from the package, handle the board care-
fully to avoid the discharge of static electricity, which can damage some
components.
Figure 1-1
connector locations, and LEDs used in installation. Confirm that your
board is in the default configuration before using the board.
EZ-Board Installation
For correct operation, install the software in the order presented in the
VisualDSP++ Installation Quick Reference Card. Substitute instructions in
step 3 with instructions in this section.
There are two options to connect the EZ-Board hardware to a personal
computer (PC) running VisualDSP++ 5.0: via an Analog Devices emula-
tor or via a standalone debug agent module. The standalone debug agent
allows a debug agent to interface to the ADSP-BF518F EZ-Board. The
standalone debug agent is shipped with the kit.
1-4
shows the default jumper and switch settings,
ADSP-BF518F EZ-Board Evaluation System Manual
