Connectors
Part Description
50-position 0.1", SMT socket
Expansion Interface II Connector (P3)
is a board-to-board connector providing signals for the PPI, TWI, and
P3
GPIO signals of the processor. The connector is located on the upper edge
of the board. For more information, see
page
1-23. For availability and pricing of the connector, contact Samtec.
Part Description
70-position 0.1", SMT header
70-position 0.1", SMT socket
DMAX Land Grid Array Connectors (P5–7)
The land grid array areas (
cessor signals. The pads are exposed and designed to attach a Tektronix
logic analyzer to the connectors listed in the following table. For more
information about the land grid array, consult the Tektronix Web site.
Part Description
Primary retention
Alternate retention
2-28
Manufacturer
Mating Connector
SAMTEC
Manufacturer
SAMTEC
Mating Connector
SAMTEC
) are intended for the probing of the pro-
P5—7
Manufacturer
TEKTRONIX
TEKTRONIX
ADSP-BF518F EZ-Board Evaluation System Manual
Part Number
SSW-125-22-F-D-VS
"Expansion Interface II" on
Part Number
TSSH-135-01-L-DV-A
SSW-135-22-F-D-VS
Part Number
020290800
020291000
