Analog Devices EZ-Board ADSP-BF518F Manual page 93

A
1
2
3.3V
D1
MA3X717E
20MA
DIO005
J12
2 1
3
BATT_COIN16MM
BATTHOLDER
"RTC BATTERY"
4
A
B
VDDEXT
U12
7
VDDEXT1
24
VDDEXT2
35
VDDEXT3
49
VDDEXT4
128
VDDEXT5
129
VDDEXT6
136
VDDEXT7
145
VDDEXT8
148
VDDEXT9
158
VDDEXT10
VDDMEM 170
VDDEXT11
59
VDDMEM1
68
VDDMEM2
75
VDDMEM3
82
VDDMEM4
95
VDDMEM5
104
VDDMEM6
112
VDDMEM7
VDDINT
124
VDDMEM8
14
VDDINT1
23
VDDINT2
30
VDDINT3
63
VDDINT4
79
VDDINT5
98
VDDINT6
100
VDDINT7
116
VDDINT8
138
VDDINT9
152
VDDINT10
VDDFLASH
164
VDDINT11
16
VDDFLASH1
17
VDDFLASH2
29
VDDFLASH3
126
VDDFLASH4
C34
0.01UF 142
VDDRTC
0402 VPPOTP VDDOTP
9
VDDOTP
8
VPPOTP
ADSP-BF518F
C40 C35 LQFP176_SOCKET
0.1UF 0.01UF
0603 0402
B
VDDEXT
C7 C37
10UF 10UF
0805 0805
1
GND1
2
GND2
15
GND3
22
GND4
43
GND5
44
GND6
45
GND7
46
GND8
VDDMEM
67
GND9
83
GND10
87
GND11
88
GND12
89 C10 C16
GND13
10UF 10UF
90 0805 0805
GND14
99
GND15
111
GND16
131
GND17
132
GND18
133
GND19
134
GND20
137
GND21
139
GND22
149 VDDINT
GND23
151
GND24
157
GND25
163
GND26
169 C15 C14
GND27
10UF 0.1UF
175 0805 0402
GND28
176
GND29
177
GND30
VDDFLASH
C41 C42
0.1UF
10UF
0805 0402
C
C6 C5 C4 C39 C8 C22
0.1UF 0.1UF 0.1UF 0.1UF 0.01UF 0.01UF
0402 0402 0402 0402 0402 0402
C9 C25 C19 C18 C20 C17
0.1UF 0.1UF 0.01UF 0.01UF 0.01UF 0.01UF
0402 0402 0402 0402 0402 0402
C13 C12 C11 C31 C30 C32
0.1UF 0.1UF 0.1UF 0.01UF 0.01UF 0.01UF
0402 0402 0402 0402 0402 0402
C43 C44 C45
0.1UF 0.1UF 0.1UF
0402 0402 0402
ANALOG
DEVICES
ADSP-BF518F EZ-BOARD
Title
DSP POWER, BYPASS CAPS
Size Board No.
C
Date 12-17-2008_11:04
C
D
1
C23 C21 C24 C38
0.01UF 0.01UF 0.01UF 0.01UF
0402 0402 0402 0402
C27 C26
0.01UF 0.01UF
0402 0402
2
C29 C33 C28 C36
0.01UF 0.01UF 0.01UF 0.01UF
0402 0402 0402 0402
3
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
Rev
A0217-2008
0.2
Sheet 3 of 16
D
