A Standard Models - Omron SYSMAC mini SP10 Operation Manual

Name
SP10 PC 6 inputs (DC; one common)
4 outputs
(2 commons, 2 pts each)
SP16 PC 10 inputs
(DC; one common, 2 pts;
one common, 8 pts)
6 outputs
(3 commons, 2 pts each)
SP20 PC 12 inputs
(DC; 2 commons, 2 pts each;
one common, 8 pts)
8 outputs
(4 commons, 2 pts each)
Programming Vertical, hand-held with backlit LCD display. Compatible with Memory Cards.
Console Memory Card and Connecting Cable sold separately (see below). Usable only
with SP-series PCs.
Programming Connect Programming Console to CPU or to
Console Link Adapter. Same as 2-m and 4-m Link
Connecting Cable Adapter Connecting Cables.*
Link Used to link up to 4 SP-series CPUs. Cables sold separately (see below).
Adapter
Link Adapter Connect the CPUs and Link Adapter.*
Connecting Cable
Memory Card 16-Kbyte SRAM cards (battery built in). Battery will last 5 years from when it is
mounted to the Memory Card.
Mounting 50-cm DIN Track
Accessories
1-m DIN Track
1-m DIN Track
End Plate
Spacer
Appendix A
Standard Models
Specifications
100 to 240 VAC Relay outputs
24 VDC
100 to 240 VAC Relay outputs
24 VDC
100 to 240 VAC Relay outputs
24 VDC
Transistor outputs
Relay outputs
Transistor outputs
Transistor outputs
Relay outputs
Transistor outputs
Transistor outputs
Relay outputs
Transistor outputs
2-m cable
4-m cable
20-cm Do not connect
cable to Programming
1-m Console.
cable
2-m cable
4-m cable
Depth 7.3 mm
Depth 16.0 mm
Model number
SP10-DR-A
SP10-DT-A
SP10-DR-D
SP10-DT-D
SP16-DR-A
SP16-DT-A
SP16-DR-D
SP16-DT-D
SP20-DR-A
SP20-DT-A
SP20-DR-D
SP20-DT-D
SP10-PRO01-V1
SP10-CN221
SP10-CN421
SP10-AL001
SP10-CN211
SP10-CN121
SP10-CN221
SP10-CN421
HMC-ES141
PFP-50N
PFP-100N
PFP-100N2
PFP-M
PFP-S
131
